Model No: C33255000

Edwards SP16K C33255000 SPEEDIVALVE，manual diaphragm valve

Condition: New
It can be directly connected to any vacuum pump or system component that has a KF16 port.

Delivery :

FOB CIF

minimum order :

1

Stock Time :

3~7Day

Quantity :

US $245.00

US $120.00 To via UPS Estimated Delivery on 3-14

Buy Now

add to cart

Contact Now

Edwards SP16K C33255000 SPEEDIVALVE manual diaphragm valve

The construction consists essentially of a flexible elastomeric diaphragm which is sealed onto a lightly polished seat by a screw thread mechanism. The mechanism is isolated from the system by the diaphragm resulting in an extremely rugged and ‘dirty’ system tolerant valve.

Features & Benefits

Visual open/closed indication (for SP10K–SP25K)
Diaphragm fully isolates the actuation mechanism from the vacuum system
Tolerant of “dirty” or particulate‑laden processes
Rugged construction; withstands 9 bar overpressure
Materials:
- Body: aluminium alloy (BS1490)
- Handwheel & bonnet: glass‑reinforced plastic
- Diaphragm: fluoroelastomer (FKM) – excellent chemical and temperature resistance

Applications

Suitable for high‑vacuum systems where isolation of the mechanism from the process is required. The SP16K is ideal for panel mounting (up to 3 mm panel thickness) or pipeline support, and can handle moderate overpressure.
